Dragonfly 1000 W PoE Switch Power Supply
1U industrial power supply delivering 1000 W at 57 VDC for PoE switches.
1000 W
Power rating
≥ 93%
Peak efficiency
Specifications
- Input voltage
- 85–264 VAC
- Nominal input
- 110 VAC
- Output voltage
- 57 VDC ± 2%
- Output current
- 20 A
- Output power
- 1000 W
- Efficiency
- ≥ 90% (≥ 93% pref.)
- Power factor
- ≥ 0.95 @ full load
- Inrush current
- ≤ 40 A (cold start)
- Isolation voltage
- 4.25 kV
- Ripple & noise
- ≤ 100 mVp-p
- OVP
- ≥ 60 VDC, auto-recover
- OCP
- ≥ 18 A, auto-recover
01 /Overview
Product details
Dragonfly is a 1U rack-mount industrial power supply that delivers 1000 W of continuous output at 57 VDC / 20 A from a universal AC line, sized for high-port-count PoE network switches.
Active power-factor correction (≥ 0.95) and 4.25 kV isolation keep it grid-friendly and safe, while active cooling with thermal feedback holds output across a wide −20 °C to +85 °C range. Auto-recovering OVP, OCP, SCP and OTP guard the load.
At a glance
- Input
- 85–264 VAC (110 VAC nom.)
- Output
- 57 VDC / 20 A
- Isolation
- 4.25 kV
- Cooling
- Active w/ thermal feedback
- Dimensions
- 1U (19.5 × 1.75 × 16 in)
- Operating temp.
- −20 °C to +85 °C
1000 W
Power rating
≥ 93%
Peak efficiency
85–264 VAC
Input voltage
110 VAC
Nominal input
02 /Engineering detail
What it does and how
Applications
APP- Power-over-Ethernet (PoE) network switches
- Telecom and networking infrastructure
- Industrial 1U rack power systems
Technologies
TECH- Active power-factor correction (PFC)
- Active cooling with closed-loop thermal feedback
Benefits
BEN- High efficiency up to ≥ 93% at full load
- Auto-recovering OVP / OCP / SCP / OTP protection
- Broad −20 °C to +85 °C operating range
- Safety compliance: UL, CE, CUL, CB
05 /Build & integration
Mechanical, environmental & I/O
Mechanical
- Cooling
- Active with thermal feedback
- Dimensions
- 1U (19.5 × 1.75 × 16 in)
- Noise level
- ≤ 55 dB
Environmental
- Operating temperature
- −20 °C to +85 °C
- Compliance
- FCC Part 15B · CE · IEC · UL · CB
07 /Documentation
Technical documents
09 /Next step
Need the Dragonfly 1000 W PoE Switch Power Supply tailored to your spec?
We adapt power stage, magnetics and protection to your envelope — from sample to volume production.
