Aomushi 800 W VSH Charger
R&D project: 800 W wide-range reconfigurable battery charger.
800 W
Power rating
Specifications
- Output power
- 800 W
- Input voltage
- 90 – 264 VAC
- Input frequency
- 50 / 60 Hz
- Output voltage
- 14.4 – 61.2 (software configurable) VDC
01 /Overview
Product details
R&D project: 800 W wide-range reconfigurable battery charger.
One charger platform serves many battery voltages and chemistries. Wide universal AC input for global deployment. Compact, high-power-density design.
At a glance
- Topology
- Wide-input PFC + charger
800 W
Power rating
90 – 264 VAC
Input voltage
50 / 60 Hz
Input frequency
14.4 – 61.2 (software configurable) VDC
Output voltage
02 /Engineering detail
What it does and how
Applications
APP- Wide-range battery charging across many pack configurations (20+ output patterns)
- Reconfigurable charging for diverse e-mobility platforms
Technologies
TECH- Wide-input PFC front end for 90 – 264 VAC operation
- Reconfigurable output stage supporting 20+ voltage patterns
- Planar-magnetics power conversion for compact, efficient design
Benefits
BEN- One charger platform serves many battery voltages and chemistries
- Wide universal AC input for global deployment
- Compact, high-power-density design
03 /How it works
Block diagram
07 /Documentation
Technical documents
09 /Next step
Need the Aomushi 800 W VSH Charger tailored to your spec?
We adapt power stage, magnetics and protection to your envelope — from sample to volume production.
